Material Handling Forklift Quick Details
Type:Powered Pallet Truck
Power Souce:Diesel Engine
Rated Loading Capacity:4000kg
Max. Lifting Height:6000mm
Min. Lifting Height:3000mm
Fork Length:1070mm
Fork Width:130mm
Overall Dimensions:2885*1480*2105mm
Certification:CE ISO TUV GS SGS
After-sales Service Provided:Engineers available to service machinery overseas
color:As per for you
load center:500mm
engine:C498BPG
Color:As per for you
Material Handling Forklift specification:
| model |
CPCD40-X8 |
| Power type |
|
diesel |
| Rated capacity |
kg |
4000 |
| Load center |
mm |
500 |
| Mast Lifting height |
mm |
3000 |
| Fork size |
Length*Width*Thickness |
mm |
1070x150x50 |
| Tilting angles |
Front/Rear |
. |
6/12 |
| Min. Turning Radius |
mm |
2700 |
| Min. intersecting stacking aisle |
mm |
4420 |
| Min. intersecting aisle |
mm |
2685 |
| Min. ground clearance |
mm |
140 |
| Overhead guard height |
mm |
2105 |
| Front overhang |
mm |
500 |
| Max. driving speeds |
km/h |
19.5 |
| Max. lifting speeds |
mm/s |
400 |
| Max. grade ability |
% |
20 |
| Length without fork |
mm |
2895 |
| Overall width |
mm |
1410 |
| Max. lift |
mm |
4160 |
| Mast height |
mm |
2127 |
| Tires |
Front |
mm |
250-15-16PR |
| Rear |
mm |
6.5-10-10PR |
| Wheelbase |
mm |
1900 |
| Tread |
Front/ Rear |
mm |
1160/1065 |
| |
Self-possessed |
Kg |
5310 |
| Battery |
Voltage/Volume |
V/Ah |
12/105 |
| Engine |
Model |
|
498BPG |
| Rated output |
kw/r.p.m |
45/2500 |
| Rated torque |
Nm/r.p.m |
198/1800 |
| No.of cylinder |
|
4 |
| Displacement |
L |
3.168 |
| Fuel tank capacity |
L |
80
|
Company Information
Anhui VMAX Machinery Manufacturing Co., Ltd. Is located in Lu'an, Anhui, China. We are one of the biggest forklift manufacturers in China, which has 67, 000 square meter area workshop and outputs 5, 000 sets forklifts annually. We have different kinds of large blazing cutter, plasma cutter, large punch machine, CNC machining center, large painting machine and other high-class machines and testing equipment, which ensure perfect quality of each forklift from VMAX. Now our products include counterbalance diesel for klift, battery forklift, gas/LPG forklift, pallet truck, stacker, reach truck, mast mobile container crane, etc. With firstclass technology and stable quality, VMAX products won the appreciation form majority of overseas customers. Our products have been exported to Europe, America, the Middle East, Southeast Asia, Africa and many other countries and regions. More than 400 VMAX members offer you products with top-class service. We sincerely welcome you to visit.
