Chinese 1.5 Ton Electric Four Wheel Drive Forklift With Side Shifter / AC Motor

Product Details:

Place of Origin:	ANHUI,CHINA
Brand Name:	VMAX
Certification:	CE ISO
Model Number:	CPD15

Payment & Shipping Terms:

Minimum Order Quantity:	1UNIT
Price:	Negotiable
Packaging Details:	bubble wrap
Delivery Time:	45 DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000unit / year

Contact Now

Detailed Product Description

Product Name:	Compact Forklift Trucks	Max. Lifting Height:	6000mm
Min. Lifting Height:	3000mm	Color:	Red Yellow
Power Souce:	AC Motor	Rated Loading Capacity:	1500kg
Fork Length:	1070mm	Fork Width:	122mm
High Light:	warehouse stand up forklift , heavy duty forklift

Chinese 1.5 Ton Electric Four Wheel Drive Forklift With Side Shifter / AC Motor

electric counterbalance forklift Characteristics

Integrated central control box the reliability of electric system
Ergonomical design ensures best operation
Energy-saving hydraulic system decreases fuel consumption
High-quality hydraulic hoses, no oil leakage
Wide-view mast design improves the productivity and safety

electric counterbalance forklift details :

Electric forklift truck with 1,500kg load capacity

Model: CPD15

AC Motor,battery charger

Standard with 2-stage wide-view mast, lifting height is 3,000mm

Pneumatic tires, 920mm forks,Safety seat,Free tool box and spare parts.

Back-up buzze, rearview mirror, full set of lights and so on.

electric counterbalance forklift specification:

Characteristics
1	4-wheel AC Power Pneumatic Tire Electric Forklift				CPD15	CPD10
2	Capacity	at rated load center		kg	1500	1000
2	Capacity	at load center - distance		mm	500
3	Power	diesel, Gasoline / LPG, electric			electric
4	Tire Type	solid, pneumatic			pneumatic
5	Wheels (x = drive)		number front / rear		2x2
Dimensions
6	Lift Height with standard two-stage mast (VM)			mm	3000
7	Free Lift Height			mm	162	162
8	Fork size		LengthWidthThickness	mm	920x100x40	920x100x40
9	Fork spacing (Min./Max.)		out-to-out	mm	200/968	200/968
10	Mast tilt angle		Forward / Backward	deg	6/12	6/12
11	Overall dimensions	length (without fork)		mm	2056	2056
		width (standard)		mm	1090	1090
		height	with lowered mast	mm	1995	1995
			with extended mast	mm	4042	4042
			to top of overhead guard	mm	1820	1820
12	Turning radius (outside)			mm	1820	1820
13	Load distance (centerline of front axle to front face of forks)			mm	429	429
Performance
14	Speeds	Travel speed	loaded	km/h	11	11.5
15		Travel speed	empty	km/h	13	13.5
16		Lifting speed	loaded	mm/sec	285	300
17		Lifting speed	empty	mm/sec	390	400
18	Gradeability		loaded/empty	%	15	15
Self Weight
19	empty	with minimum weight battery		Kg	3120	2900
Chassis
20	Tyre Size	Front, standard pneumatic tires			6.5-10-10PR	6.5-10-10PR
21	Tyre Size	Rear, standard pneumatic tires			5.00-8-8PR	5.00-8-8PR
22	Wheel base			mm	1250	1250
23	Tread width		Front	mm	890	890
23	Tread width		Rear	mm	920	920
24	Min. Under-clearance (full load / no load )		at lowest point at mast	mm	95/110	85/105
25	Min. Under-clearance (full load / no load )		at center of wheelbase	mm	95/105	120/140
Powertrain
26	Battery	Voltage		V	48	48
27	Battery	Capacity		AH	400/440/480	630/700
28	Electric motor	Drive motor output		kw/rpm	5.3/1700	5.3/1700
29	Electric motor	Hydraulic motor output		kw/rpm	8.2/1600	8.2/1600
30	controller				Italian SME /GE/USA CURTIS AC controller
