5HPX Series Tower Type Paddy Drying Equipment Grain Dryer
The 5HXG Series Tower Type Grain Dryer can be used in drying paddy, wheat, barley, oil seeds, maize, soya bean and pea, etc. And it is also workable for drying rice seeds. In addition, the combustion furnace can provide clean hot air for heating sunlight glasshouses, plant greenhouses and various kinds of buildings.
1. Hot blast stove supplies heat, indirect heating grain;
2. Low temperature balanced drying can reduce the grain broken rate,improve the head rice yield;
3. Different kind of furnace/burner for your choice.
5HPX Series Tower Type Paddy Drying Equipment Grain Dryer TECHNICAL PARAMETERS
| Product Description |
| Model |
5HPX-15 |
5HPX-20 |
5HPX-30 |
5HPX-30B |
5HPX-35 |
| Loading capacity(kg) |
Paddy |
3,000~15,000 |
3,000~20,000 |
4,000~30,000 |
4,000~30,000 |
5,000~35,000 |
| |
Corn |
3,800~18,500 |
3,800~24,600 |
5,000~36,400 |
5,000~36,400 |
6,000~42,000 |
| Dimension L*W*H (mm) |
4321*2583*10000 |
4600*3263*10500 |
4600*3260*12700 |
4600*3570*12700 |
5712*5000*12400 |
| Net Weight |
3,000 |
4,200 |
5,500 |
6,500 |
8,000 |
| Heat Source |
Biomass Furnace/Gas Burner/Diesel Burner |
| Power Consumption (kw) |
9.95 |
10.6 |
15.45 |
21.7 |
19.7 |
| Input Voltage |
3 Phase 220V/380V,50Hz |
| Husk Furnace |
Type |
Indirect |
| |
Ignition |
Manual |
| Function |
Loading |
50~60(approx) |
50~60(approx) |
60~70(approx) |
60~70(approx) |
60~70(approx) |
| |
Discharge |
50~60(approx) |
50~60(approx) |
60~70(approx) |
60~70(approx) |
60~70(approx) |
| |
Drying Rate |
0.5-1.2 %/h |
0.5-1.2 %/h |
0.6-1.2 %/h |
0.6-1.4 %/h |
0.5-1.2 %/h |
| Standard Devices |
Online moisture meter, Conveyor ,Discharge system, Buffer system, Elevator ,Suction fan, Temperature sensor |
| Safety Devices |
Overload device, Temperature control device, Control fuse, Leakage protection device, Air pressure switch |
Furnace Burner Options
| Furnace Type |
Yes/No |
| Diesel |
Yes |
| Gas |
Yes |
| Coal |
Yes |
| Biomass Material |
Yes(Husk/Wood/Straw/Etc) |
5HPX Series Tower Type Paddy Drying Equipment Grain Dryer FEATURES:
1. Dry area is large, good drying medium penetrability, good uniform moisture of dried product, high efficiency.
2. Hot blast stove supplies heat, indirect heating grain. During dry process, grain continuous cycling, grain fricting each other, removing the awn, fuzz, etc. of grain surface, and the duster remove these above out of machine, improving the dried grain clearness.
3. Low temperature balanced drying can reduce the grain crack ratio, improve the head rice yield, so as to enhance the quality of rice.
4.Control system adopts the man-machine interface display dryer running status, the operation is simple, automatic display faults be clear at a glance, easy to quickly find out and eliminate faults, safe and practical.
5. The dryer without dead angle for residual grain, even easy cleaning, preventing mixing different kinds of grain.
6. The KETT resistance type online moisture detector. Automatic determination of moisture, and control the speed of removing moisture of grain. It is a high precision sensor and control equipment, when moisture reaches set point, I will let equipment automatic stop.
7. Drive bearings all be designed for low speed, three layer dust protection, dust can’t enter to internal when the bearing on operating.
8. We use mixed flow fans instead of centrifugal fans and axial flow fans, the largest air volume will reach 17500 cubic meters/hour after warm air through fans, total pressure is 950 pa, effectively improve the drying effect and low noise.
9. The blades of screw conveyor use 45 manganese steel, Surface Hardness is HRC50
10. Using belt conveyor instead of screw conveyors on the top and bottom, greatly reducing crashed rate.
11. We also have biomass burner, which can take the husk, straw, wood, peanut stalk, corn cob (stalk) and other waste biomass as fuel. If you don't want to use oil burner, you can choose the biomass burner.
Drying Unit Diagram
What We Can Offer
1)Whole turnkey project solution
included Pre-cleaning machine,elevator,input&outlet pipe,furnace and dryer
2)Plant designition service
supply you all the possibly area required,the instllation diagram for consideration
3)Instllation and commisioning service
professional engineer woud guide you for the assembling and commisioning the machine
4)Full time online service
24 hours online technique service,ensure to tackle the problem immediately
5)Enormous spare parts to support
easy broken spares and wearing parts would be send timely,no worry for drying season
