CCD Grain Color Sorter Machine
Product Description
* Top chromatic ccd sensor, high reliability and long life source, original italian matrix or chinese high reliability ejectors,american super speed fpga processor;
* Color sorting, shape sorting and size sorting functions combined;
* Unique algorithm good at identifying tiny defects;
* 8-inches display with full-color and multilingual touch-screen, intelligent system, self-learning function,easy operation;
* Intelligent ejection system,visualization analysis, 3d recognition technology;
* Mass and high speed data transmission system with a strong anti-jamming power and a more stable data transmission. successfully solve a variety of color selections of high difficulties, meet the color sorting needs for high yield products, and provide better color sorting results;
* Add sloping chutes for sorter upgrading or production increasing, from one chute to sixteen chutes to meet any different production capacity requirement;
* More stable algorithm-auto image adjustment algorithm,refuse environment disturbance;
* Unique bionic technology camera ,new steady temperature light source,cloud computing ,massive data analysis.
Parameter Table
| Model |
ZF300 |
ZF500 |
ZF700 |
| Throughput(T/H) |
1.0-3.0 |
2.0-5.0 |
3.0-8.0 |
| Voltage(V) |
110-250V(50-60HZ) |
| Power(KW) |
1.8 |
2.6 |
3.5 |
| Weight/(KG) |
885 |
1275 |
1665 |
| Dimension(L*W*H/mm) |
1174*1658*2038 |
2402*1658*2038 |
3030*1658*2038 |
| Sorting accuracy(%) |
≥99 |
| Rejection rate(%) |
≥10:1 |
| Air consumption(L/min) |
800-1600 |
1300-2200 |
1800-3600 |
| Notes |
Subject to different impurities of raw materials,parameters listed in table will change to some extent |
| |
|
|
|
|
|
