Name: Orange 4 Ton Pullet Diesel Powered Forklift Truck CE BV SGS Certification
Brand: VMAX
SKU: CPCD40

Orange 4 Ton Pullet Diesel Powered Forklift Truck CE BV SGS Certification

Product Details:

Place of Origin:	ANHUI,CHINA
Brand Name:	VMAX
Model Number:	CPCD40

Payment & Shipping Terms:

Minimum Order Quantity:	1UNIT
Price:	Negotiable
Packaging Details:	bubble wrap
Delivery Time:	45 DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000unit / year

Contact Now

Detailed Product Description

Product Name:	Diesel Powered Forklift	Power Souce:	Diesel Engine
Rated Loading Capacity:	4000 Kgs	Color:	Orange
Fork Length:	1070mm	Fork Width:	125mm
High Light:	3 wheel electric forklift , four wheel drive forklift

Quick Details

Type:Powered Pallet Truck

Power Souce:Diesel Engine

Rated Loading Capacity:4000

Max. Lifting Height:4000-6000

Min. Lifting Height:3000

Fork Length:1070

Fork Width:125

Overall Dimensions:2895*1410*2105

Certification:CE,BV,SGS

After-sales Service Provided:Engineers available to service machinery overseas

Color: orange

Here are the details of standard configurations:

Diesel forklift truck with 4000kg load capacity
Model Number: CPCD40
Equipped with China engine XingchangC485BPG, Hydraulic transmission with TCM-technology
Standard with 2-stage wide-view mast, lifting height is 3, 000mm
Pneumatic tires, 1220mm forks, Safety seat, Free tool box and spare parts.
Back-up buzze, rearview mirror, full set of lights and so on.

Product Description

Model				CPCD25	CPCD30	CPCD35	CPCD40	CPCD45
Power type				Diesel
Rated capacity			kg	2500	3000	3500	4000	4500
Load center			mm	500
Mast lifting height			mm	3000
Fork size	LxWxT		mm	1070x122x40	1070x125x45	1070x125x50	1070x130x50	1070x150x50
Tilting/angles	Front/ rear			6/12
Min.Turing Radius			mm	2240	2420	2420	2700	2780
Min.intersecting aisel			mm	2010	2100	2235	2685	3365
Min.ground clearance			mm	120	110	125	130	160
Overhead guard height			mm	2070	2070	2090	2105	2290
Front overhang			mm	465	477	490	500	565
Max. driving speeds			Km/h	19	18.5/20	19	18/19	20/19
Max. lifting speeds			Mm/s	550	520	350	380	450
Max. grade ability			%	20	20	20	20	20
Length without fork			mm	2550	2680	2700	2895	3105
Overall width			mm	1150	1225	1225	1410	1480
Max. lift			mm	4030	4250	4250	4275	4280
Tires		Front	mm	7-12-12PR	28*9-15-12PR	28*9-15-12PR	250-15-16PR	300-15-18PR
Tires		Rear	mm	6-9-10PR	6.5-10-10PR	6.5-10-10PR	6.5-10-10PR	7-12-12PR
Wheelbase			mm	1600	1700	1700	1900	2000
Tread		Front/ Rear	mm	970/970	1000/970	1000/970	1160/1065	1180/1190
Tread		Self- possessed	kg	3700	4300	4900	5310	6400
Battery		Voltage/ Volume	V/Ah	12/80	12/80	12/80	12/80	12/80
Engine		Model		XinchangC490BP	XinchangC490BPG	XinchnagA495BP	XinchangA498BP	Yituo LR4B3-G
		Rated output	kw/r.p.m	37/2650	37/2650	42/2650	45/2650	61/2200
		Rated torque	Nm/r.p.m	148/1800	148/1800	174/1800-1900	198/1800	288/1600
		No.of cylinder		4	4	4	4	4
		Displacement	L	2.54	2.54	2.98	3.168	4.58
Fuel tank capacity			L	60	60	60	70	80

Packaging & Shipping

A: Date of delivery: 15-25days after received the deposit
B: Payment terms: T/T(30% deposit, balance paid before shipment). Or L/C at sight
C: Guaranty period: One year or 2000hours upon receiving goods.
